Wisking 1023-22

Type: 1023-22

Color:

Long range of around 40KM for the middle wheelchair.

Seat and backrest cushion can be easily remove for cleaning.

Controllers can be interchanged with right and left side.

Easy access tiller-mounted charger port.

Modern design Led lights for all lights.

Specification

  • Length

    112cm

  • Width

    6cm

  • Height

    104cm

  • Weight capacity

    150kg

  • Wheels

    Front:10”air tire Rear:14”air tire

  • Incline capability

    12 degrees

  • Max.forward speed

    8-10km/h

  • Range

    up to 40km per battery charge

  • Controller

    PG(Imported from UK)

  • Motor

    24V/320W*2(Imported from Taiwan)

  • Charger

    24V/5A

  • Battery

    12V/55AH*2

  • suspention

    Front:with Rear:optional

  • Recharge time

    10-12hrs

  • Seat depth

    45cm

  • Seat width

    45cm

  • Seat height

    55cm

  • Net weight(with batteries)

    90kg

  • Net weight(without batteries)

    56kg

  • Battery dimension

    23*13.8*22.6cm*2

  • Packge

    2ctns
